Technical Specifications
| Work zone | Upper body | Dorsal | Trapeze | Rhomboids |
|---|---|
| Dimensions | 135 cm x 175 cm x 207 cm |
| Net weight | 101 kg |
| Structure | Steel tube of 100 × 50 mm and 75 × 50 mm, welded by A robotic process, completely free of protrusions. Plates 8 and 10 mm structural joining for an extra rigid joint |
| Max user weight | 150 kg |
| Max load weight | It accepts Olympic weight plates up to a limit of 250 kg, 125 kg per arm. |
| Plate holder | Steel tube coated with technopolymer. Dimensions: Ø50 mm × 250 mm |
| Bushings | Calibrated steel Ø65 mm, 8 mm. |
| Bearings | High precision 6205 bearings |
| Axles | Made of calibrated 20# steel, Ø25 mm |
| Grips | Double grip made with steel tube Ø34 mm × 170 mm, with non-slip PVC coating and aluminum plugs |
| Backrest and seat | Made from high-density EVA for greater comfort. Thickness: 60 mm |
| Upholstery | Leather-like finish, very durable against friction and wear. Sweat-resistant and antibacterial |
| Adjustment system | 6 pop pin positions. |
| Bases | Height-adjustable plastic leveling feet. |
| Base protection | Plastic levelers. |
| Hardware | M10, resistance class 8.8. |
| Painting system | Electrostatic coating. |
| Platform | Non-slip surface. Tilt adjustment: 4 levels. |
Solid Rock SRX
Featured
Disk drive
Isolatoral movements
Maximum stability
Structure
D-shaped base
