Technical Specifications
| Bases | 4 non-slip ferrules. |
|---|---|
| Dimensions | 153 cm x 157 cm x 115 cm |
| Axles | Laser-cut 10mm thick plates with another 10mm thick plate for reinforcement, to achieve smooth movement without play or twisting caused by continuous use or load. |
| Empunadoras | Anodized aluminum, knurled for improved grip. |
| Structure | Steel tubes 110 x 52 mm with a thickness of 3 mm. |
| Materiales y acabados | 20mm thick rubber finishes on the Disc holders. 50mm rubber finishes mm thick to support the moving parts. |
| Palancas de regulacion | Adjustable seat via pop-pin. Single-bolt adjustment system, manufactured from techno-polymer with a breaking index 750 kg. |
| Net weight | 175 kg |
| Proceso de pintura | 3 layers of paint. Pickled and stabilized steel using total immersion of the pieces in different degreasing solutions to guarantee a perfect and complete cleaning of the material base. |
| Bearings | SKF double tapered roller bearing, housed in a closed, anti-play bushing, ensuring a constant direction of movement. |
| Work zone | Lower body | Quadriceps |
-
ADJUSTABLE SEAT
AT VARIOUS HEIGHTS
