Technical Specifications
| Grips | Made of 36 mm diameter x 350 mm steel tubing, with non-slip PVC cover and aluminum trims. |
|---|---|
| Bases | Made from injection-molded technopolymer, ultra-resistant and non-slip. Screws to the floor. |
| Max load weight | It accepts Olympic weight plates up to a limit of 150 kg (75 kg per arm). |
| Dimensions | 109 cm x 71 cm x 128 cm |
| Axles | Made of calibrated steel 25 mm thick. |
| Structure | Steel tubing 76 x 51 mm and 51 x 51 mm for moving parts, welded through a robotic and free process Projections. 6 mm structural joining plates for an extra rigid connection. |
| Mantenimiento y lubricacion | Bi-weekly maintenance. Lubrication of seatposts, guides, bearings and pop pin. Cleaning of upholstery with a damp cloth. |
| Max user weight | 150 kg |
| Net weight | 47 kg |
| Proceso de diseno | Biomechanical and ergonomic study under the Supervision by professionals and associated athletes. After a long design period; from the initial sketch, engineering research, prototype production, and testing by professional athletes, our products are launched on the market. |
| Proceso de pintura | 3 layers of paint. Pickled and stabilized steel using total immersion of the pieces in different degreasing solutions for to guarantee a perfect and complete Cleaning the base material. Priming antioxidant to ensure a adequate protection from oxidation internal and good adhesion of the Paint. Two final coats of epoxy paint. polyester powder, dried at 240°C. |
| Backrest and seat | Made of high-density polyurethane foam, extra comfortable. 7 cm thick. |
| Bearings | SKF double bearing 52 mm diameter x 15 mm housed in a closed anti-play bushing, ensuring a constant direction of movement. |
| Plate holder | Steel tube coated with a PVC sleeve, increasing durability. Tube dimensions: 250 mm. |
| Upholstery | Carbon Fiber faux leather finish. Large Durable against friction and wear. Prepared to resist perspiration and antibacterial properties. |
| Work zone | Upper body | Biceps | Triceps |
-
