Technical Specifications
| Grips | Made of steel, with non-slip PVC cover and aluminum trim. Double grip, for leg raises and dips. |
|---|---|
| Bases | Coated in non-slip rubber. |
| Dimensions | 141 cm x 82.5 cm x 46 cm |
| Structure | 100x50 mm, 2.5 mm thick steel tube, robotically welded, free of spatter. 6 mm structural connection plates for extra rigid connection. |
| Mantenimiento y lubricacion | Bi-weekly maintenance. Lubrication of seat posts, guides, bearings, and pop pins. Clean upholstery with a damp cloth. |
| Materiales y acabados | High quality finish. 3.5mm thermoplastic ABS end caps. |
| Max user weight | 150 kg |
| Net weight | 42 kg |
| Proceso de diseno | Biomechanical and ergonomic study under the Supervision by professionals and associated athletes. After a long design period; from the initial sketch, engineering research, prototype production, and testing by professional athletes, our products are launched on the market. |
| Proceso de pintura | 3 layers of paint. Pickled and stabilized steel by total immersion of the parts in different solutions Degreasers to ensure perfect and complete cleaning of the base material. Anti-rust primer to guarantee adequate protection against internal oxidation and good paint adhesion. Two final coats of polyester epoxy paint. powder, dried at 240°C. |
| Upholstery | Carbon Fiber leatherette finish. Highly durable against friction and wear. Resistant to perspiration and antibacterial. |
